Fixed Lite
Windows
Fixed Lite Windows
Fixed-Lite windows have a picture frame look and concealed fixings allowing open, unhindered views and maximum light. This window is great as a feature window on it’s own or complements the window and door ranges at Wunderbar.
Our Range
Essential Range
The Essential Fixed-Lite window has a picture frame look and concealed fixings allowing open, unhindered views and maximum light. This window is great as a feature window on it’s own or complements the window and door ranges at Wunderbar.
Performance Parameters
-
Frame size 52mm
-
Maximum window height 3010mm
-
Maximum panel width 3010mm
-
Maximum panel weight N/A
-
Maximum water rating 450Pa
-
Maximum wind rating 4500Pa ULS
-
Maximum glass thickness 12.38mm (single glazed) 24mm (IGUs)
-
Maximum acoustic rating Rw35
-
Maximum bushfire attack level BAL 40
{"items":["636af949-f7c2-49bf-a5a8-585888597640","6ccbc2d4-9a60-4458-be08-ee3b6a0f061e","388d6269-afd1-400c-9f2a-00af525ad129","a8f9a09d-5d73-4bfa-9154-741932d7eb78"],"styles":{"galleryType":"Strips","groupSize":1,"showArrows":true,"cubeImages":true,"cubeType":"fill","cubeRatio":"100%/100%","isVertical":false,"collageAmount":0.8,"collageDensity":1,"groupTypes":"1","oneRow":true,"imageMargin":0,"galleryMargin":0,"floatingImages":0,"chooseBestGroup":true,"smartCrop":false,"hasThumbnails":true,"enableScroll":true,"isGrid":false,"isSlider":false,"isColumns":false,"isSlideshow":false,"cropOnlyFill":false,"fixedColumns":0,"enableInfiniteScroll":true,"isRTL":false,"minItemSize":120,"rotatingGroupTypes":"","rotatingCubeRatio":"","gallerySliderImageRatio":1.7777777777777777,"numberOfImagesPerRow":3,"numberOfImagesPerCol":1,"groupsPerStrip":0,"borderRadius":0,"boxShadow":0,"gridStyle":0,"mobilePanorama":false,"placeGroupsLtr":false,"viewMode":"preview","thumbnailSpacings":9,"galleryThumbnailsAlignment":"bottom","isMasonry":false,"isAutoSlideshow":false,"slideshowLoop":false,"autoSlideshowInterval":4,"bottomInfoHeight":0,"titlePlacement":"SHOW_ON_HOVER","galleryTextAlign":"left","scrollSnap":true,"itemClick":"expand","fullscreen":true,"videoPlay":"hover","scrollAnimation":"NO_EFFECT","scrollDirection":1,"overlayAnimation":"NO_EFFECT","arrowsPosition":0,"arrowsSize":23,"watermarkOpacity":40,"watermarkSize":40,"useWatermark":true,"watermarkDock":{"top":"auto","left":"auto","right":0,"bottom":0,"transform":"translate3d(0,0,0)"},"loadMoreAmount":"all","defaultShowInfoExpand":1,"allowLinkExpand":true,"expandInfoPosition":0,"allowFullscreenExpand":true,"fullscreenLoop":false,"galleryAlignExpand":"left","addToCartBorderWidth":1,"addToCartButtonText":"","slideshowInfoSize":200,"playButtonForAutoSlideShow":false,"allowSlideshowCounter":false,"hoveringBehaviour":"APPEARS","thumbnailSize":120,"magicLayoutSeed":1,"imageHoverAnimation":"NO_EFFECT","calculateTextBoxWidthMode":"PERCENT","textBoxHeight":0,"textBoxWidth":200,"textBoxWidthPercent":50,"textImageSpace":10,"textBoxBorderRadius":0,"textBoxBorderWidth":0,"loadMoreButtonText":"Load More","loadMoreButtonBorderWidth":1,"loadMoreButtonBorderRadius":0,"imageInfoType":"NO_BACKGROUND","itemBorderWidth":0,"itemBorderRadius":0,"itemEnableShadow":false,"itemShadowBlur":20,"itemShadowDirection":135,"itemShadowSize":10,"imageLoadingMode":"BLUR","expandAnimation":"NO_EFFECT","imageQuality":90,"usmToggle":false,"usm_a":0,"usm_r":0,"usm_t":0,"videoSound":false,"videoSpeed":1,"videoLoop":true,"gotStyleParams":true,"selectedLayout":"3|bottom|1|fill|false|1|true","allowSocial":false,"allowDownload":false,"allowTitle":false,"allowDescription":false,"loveButton":false,"loveCounter":false,"showVideoPlayButton":true,"galleryImageRatio":2,"sharpParams":{"quality":65,"usm":{}},"galleryHorizontalAlign":"flex-start","galleryVerticalAlign":"flex-end","imageLoadingWithColorMode":"PICKED_COLOR","imageRatioType":"FIXED","numberOfDisplayedItems":3,"itemBorderColor":"color-5","itemShadowOpacityAndColor":{"value":"rgba(0, 0, 0, 0.2)"},"textBoxBorderColor":"color-5","titleDescriptionSpace":6,"textsVerticalPadding":0,"textsHorizontalPadding":0,"textBoxFillColor":"color-2","alwaysShowHover":false,"isStoreGallery":false,"previewHover":false,"calculateTextBoxHeightMode":"MANUAL","galleryLayout":3,"useCustomButton":false,"customButtonText":"","itemOpacity":{"themeName":"color_14","value":"rgba(96,94,94,0.6)"},"itemFont":{"style":{"bold":false,"italic":false,"underline":false},"family":"din-next-w01-light","preset":"Heading-S","editorKey":"font_6","size":22,"fontStyleParam":true,"displayName":"Small Heading","value":"font:normal normal normal 22px/1.4em din-next-w01-light,din-next-w02-light,din-next-w10-light,sans-serif;"},"itemFontSlideshow":{"family":"avenir-lt-w01_85-heavy1475544","displayName":"Basic Heading","style":{"bold":false,"italic":false,"underline":false},"size":22,"preset":"Custom","editorKey":"font_5","fontStyleParam":true,"value":"font:normal normal normal 22px/27px avenir-lt-w01_85-heavy1475544,sans-serif;"},"itemDescriptionFontSlideshow":{"family":"avenir-lt-w01_35-light1475496","displayName":"Paragraph 2","style":{"bold":false,"italic":false,"underline":false},"size":15,"preset":"Custom","editorKey":"font_8","fontStyleParam":true,"value":"font:normal normal normal 15px/18px avenir-lt-w01_35-light1475496,sans-serif;"},"itemDescriptionFont":{"family":"avenir-lt-w01_35-light1475496","displayName":"Paragraph 2","style":{"bold":false,"italic":false,"underline":false},"size":15,"preset":"Custom","editorKey":"font_8","fontStyleParam":true,"value":"font:normal normal normal 15px/18px avenir-lt-w01_35-light1475496,sans-serif;"},"itemFontColor":{"themeName":"color_11","value":"rgba(255,255,255,1)"},"itemFontColorSlideshow":{"themeName":"color_15","value":"rgba(47,46,46,1)"},"itemDescriptionFontColor":{"themeName":"color_11","value":"rgba(255,255,255,1)"},"itemDescriptionFontColorSlideshow":{"themeName":"color_15","value":"rgba(47,46,46,1)"},"loadMoreButtonFont":{"family":"din-next-w01-light","displayName":"Paragraph 2","style":{"bold":false,"italic":false,"underline":false},"size":15,"preset":"Body-M","editorKey":"font_8","fontStyleParam":true,"value":"font:normal normal normal 15px/1.4em din-next-w01-light,din-next-w02-light,din-next-w10-light,sans-serif;"},"loadMoreButtonFontColor":{"themeName":"color_15","value":"rgba(47,46,46,1)"},"loadMoreButtonColor":{"themeName":"color_11","value":"rgba(255,255,255,1)"},"loadMoreButtonBorderColor":{"themeName":"color_15","value":"rgba(47,46,46,1)"},"arrowsColor":{"themeName":"color_11","value":"rgba(255,255,255,1)"},"responsive":false,"isAccessible":false,"allowLeanGallery":false,"layoutsVersion":2,"selectedLayoutV2":3,"isSlideshowFont":false,"externalInfoHeight":0,"externalInfoWidth":0},"container":{"top":"","bottom":"","left":"","right":"","width":678,"height":376,"position":"","avoidGallerySelfMeasure":true,"galleryWidth":678,"galleryHeight":229,"scrollBase":0}}
Signature Range
The Signature Fixed-Lite window is available from small to maxi sizes, perfect as a feature window or adding architectural detail in side-lites or hi-lites.
Performance Parameters
-
Frame size 100mm
-
Maximum window height 5325mm
-
Maximum panel width 6400mm
-
Maximum panel weight N/A
-
Maximum water rating 450Pa
-
Maximum wind rating 4500Pa ULS
-
Maximum glass thickness 12.38mm (single glazed) 24mm (IGUs)
-
Maximum acoustic rating Rw35
-
Maximum bushfire attack level BAL 40
